Hygienic DIN 11851
Hygienic DIN Elbow
7307DIN1185EL01
- Material
- Stainless Steel 304L / 316L (ASTM A270)
- Type
- Precision Machined
- Surface finish
- Ra ≤ 0.8 μm
- End Connection
- DIN 11851 Union
- Dimension Standard
- DIN 11851
- Temperature
- -10 deg C to 130 deg C
- Pressure Rating
- Up to 6 bar
- HSN Code
- 73072990
- GST
- 18%
Illustration5 columns · scroll sideways
Pricing: prices for this product are not listed. Request a quotation.
- Certification
- Surface finish cert (Ra <= 0.8 um).
- Coating
- Ra <= 0.8 um internal polish.
- Taxes & Duties
- GST and all applicable levies charged extra at prevailing rates.
All dimensions in millimetres. Subject to change without notice. Spotted a mistake or wrong data? Please contact us.
Applicable Standards
Standards governing design, dimensions, and testing
DIN 11851
Hygienic Pipe Fittings – Milk Pipe Unions (DIN 11851)
Traditional European dairy fitting standard. Slot nut and liner seal design. Common in German, Austrian, and continental European dairy equipment.
- Thread: DIN coarse thread with liner groove
- Max pressure: 6 bar; Max temp: 130°C
- Sizes: DN25 to DN150
- Material: 1.4301 (304) or 1.4404 (316L)
- Gasket: EPDM or silicone
- Not directly interchangeable with SMS or IDF
