SW Forged 6000
Forged SW Half Coupling
7307SW6000-HCO-01
- Material
- Carbon Steel (ASTM A105N)
- Type
- Forged
- Schedule
- Class 6000#
- End Connection
- Socket Weld
- Dimension Standard
- ASME B16.11
- Temperature
- -29 deg C to 427 deg C
- Pressure Rating
- Class 6000# per ASME B16.11
- HSN Code
- 73079300
- GST
- 18%
Illustration5 columns · scroll sideways
Pricing: prices for this product are not listed. Request a quotation.
- Certification
- MTR, PMI, hardness test certificates available.
- Coating
- Black paint / mill finish.
- Taxes & Duties
- GST and all applicable levies charged extra at prevailing rates.
All dimensions in millimetres. Subject to change without notice. Spotted a mistake or wrong data? Please contact us.
Applicable Standards
Standards governing design, dimensions, and testing
ASME B16.11
Forged Fittings, Socket-Welding and Threaded
Covers socket weld and threaded forged fittings in Class 2000#, 3000#, 6000#, and 9000# for small bore high-pressure service.
- Classes: 2000# (threaded only), 3000#, 6000#, 9000#
- Socket weld: ½" to 4" NB; Threaded: ¼" to 4" NB
- Material: ASTM A105N (carbon steel), A182 F304/316 (stainless)
- Gap of 1.5 mm required between pipe and socket bottom before welding
- Single fillet weld at socket face: no back-welding possible
- No pressure-temperature rating: determined by pipe schedule
